ITC T-7700 SERIES

T-7700RU2

Broadcasting System Management & Control Software

B/S Architecture • Web Remote Management • Full-Duplex Voice Exchange

ADVANCED SERVER – ENHANCED SCALABILITY
T-7700RU2 Server Software - Advanced Edition
T-7700RU2 Dashboard
ITC T-7700

Broadcasting Management Server

T-7700RU2 (Advanced Server Edition)

B/S Architecture
Web Remote
Full-Duplex
GPS Timing
Timed Tasks
Fire Linkage
5000+ Terminals
Multi‑Server

Advanced server platform for large-scale IP audio networks. Supports up to 5,000+ terminals with enhanced scalability, multi-server clustering, and advanced scheduling algorithms. Ideal for city-wide systems and mission-critical infrastructure.

Software Specifications – T-7700RU2 (Advanced)

Model NumberT-7700RU2
Product NameBroadcasting System Management Software – Advanced Edition
CategorySystem Management & Control Software (High-Capacity Server)
ArchitectureB/S (Browser/Server) – Web-based management
ManufacturerITC / Tongfang
Warranty3-Year Comprehensive (Advanced)
DeploymentHigh-performance server (T-7700A / t-7700h recommended)
Max Terminal Support5,000+ IP endpoints (scalable via clustering)
Remote AccessWeb Login, Mobile APP (Android/iOS), SDK/API
Voice ExchangeFull-Duplex with advanced echo cancellation
RedundancyNative support for T-7700SR hot backup + multi-server failover
Terminal ManagementCentralized, with advanced grouping and geo-mapping
Real-time MonitoringCustom dashboards, SNMP traps, email alerts
Task SchedulingAdvanced calendar, holiday patterns, offline ringing
Fire Alarm LinkageMulti-interface support (16/32/64 zones)
User AuthorityGranular RBAC, LDAP/Active Directory integration
Language SupportMulti-language (10+ languages)
OS CompatibilityWindows Server 2016/2019/2022, Linux (RedHat/CentOS on request)
DatabaseMySQL / SQL Server (enterprise grade)

Software Overview – T-7700RU2

The T-7700RU2 is the advanced, high-capacity server software variant of the ITC T-7700 Series. Designed for large-scale, mission-critical deployments, it extends the capabilities of the standard RU1 platform with superior scalability, multi-server clustering, and enhanced terminal management (supporting over 5,000 devices). It is the preferred choice for smart city infrastructures, metropolitan transportation networks, and nationwide broadcasting systems.

Massive Scalability

Supports 5,000+ terminals per server; multi-server clustering for virtually unlimited expansion.

Multi-Server Redundancy

Native hot-standby and N+1 failover configurations for zero downtime.

Advanced Analytics

System health dashboards, terminal usage reports, and predictive maintenance alerts.

System Architecture – High-Capacity Deployment
  • Core Server (RU2): Central management with optimized database and caching.
  • Regional Proxy Servers: Optional distributed architecture for WAN optimization.
  • T-7700SR Hot Backup: Seamless failover with real-time synchronization.
  • API Gateway: RESTful API for third-party BMS, security, and IoT integration.
  • Mobile Command Center: Full control via T-7700PA apps with enhanced permissions.
Ideal Applications
  • Smart City – public address across entire metropolitan areas
  • National railway networks – station and onboard audio
  • Large airport hubs – multi-terminal paging and emergency
  • Military bases / secure government campuses
  • Mega industrial complexes and smart factories

Key Features – T-7700RU2 (Advanced Server)

Scalability & Performance
  • ✓ Supports up to 5,000+ IP audio terminals per instance
  • ✓ Multi-server clustering and load balancing
  • ✓ 64-bit optimized multi-threaded core
  • ✓ Enterprise-grade database (MySQL/SQL Server)
  • ✓ 100,000+ scheduled tasks per day capacity
Redundancy & Reliability
  • ✓ Native T-7700SR hot backup support
  • ✓ N+1 server failover configuration
  • ✓ Real-time configuration synchronization
  • ✓ Automatic recovery after power failure
  • ✓ RAID storage support for data integrity
Advanced Management
  • ✓ Geo-mapping – visualize terminals on GIS maps
  • ✓ LDAP / Active Directory user integration
  • ✓ Role-based access with 100+ permission levels
  • ✓ Custom dashboard widgets and SNMP monitoring
  • ✓ Automated email/SMS alerts on system events
Integration & APIs
  • ✓ RESTful API for third-party system integration
  • ✓ Fire alarm systems: 64+ zone support
  • ✓ Modbus TCP interface for industrial automation
  • ✓ SDK available for custom application development
  • ✓ Integration with video surveillance systems
Recommended Hardware

T-7700A (Core i7, 256GB SSD) or t-7700h (Dual Xeon, 32GB RAM, RAID) for optimal performance. 1Gbps/10Gbps network interface recommended for large deployments.

System Compatibility – T-7700RU2

Full T-7700 Series Device Support
  • All T-7700 Series terminals (same as RU1) – 100% backward compatible
  • Paging: T-7702A, T-7702M, T-7700A/AN
  • Decoders/Amps: T-7701, T-7701Z, T-7704, T-7700B series (all power levels), T-77240Z/T-77350Z/T-77500Z
  • Speakers: T-7705A, T-7705S, T-7707 series, T-7782, T-7784, T-7782PA (PoE), T-7782POEH
  • Emergency: T-7710, T-7731 (Ex), T-7732, T-7730, T-7730P
  • Accessories: T-7713, T-7720, T-7720UH, T-7723/B, T-7770, T-7772, T-0778P, T-100PT
Software & System Compatibility
  • Server OS: Windows Server 2016/2019/2022 (Standard/Datacenter)
  • Linux Support: RedHat Enterprise Linux 8+, CentOS 7+ (custom order)
  • Database: MySQL 8.0, SQL Server 2019+
  • Virtualization: VMware, Hyper-V, KVM (supported)
  • Client: Web (any OS), T-7700RL, T-7700RP, T-7700PA (Android/iOS)
Redundancy & Clustering
  • T-7700SR – Hot backup server (automatic failover)
  • Multi-server active-standby (N+1)
  • Regional proxy for WAN optimization
API & Third-Party Integration

T-7700RU2 includes a comprehensive RESTful API for integration with building management systems (BMS), SCADA, security platforms, and custom command centers. SDK documentation available upon request.
