t-7700h (Hardware)
The ultimate enterprise platform for T-7700 series. t-7700h is a dual-socket Xeon server engineered for the largest IP audio deployments. With 12 physical cores (24 threads), 32GB ECC memory, and hybrid storage (1TB HDD + 128GB SSD), it delivers uncompromising performance for 1000+ endpoints, advanced recording, and multi-user access. IPMI 2.0 enables complete out-of-band management.
| Model Number | t-7700h |
| Product Type | Enterprise-Grade IP Network Server |
| Form Factor | 2U Rackmount (19" with rails) |
| Processor | Dual Intel Xeon E5-2643V2 (6-core, 3.5GHz, 25MB cache) – 12 cores / 24 threads total |
| Chipset | Intel C602 |
| Memory | 32GB DDR3 ECC Registered (8x 4GB, expandable to 256GB) |
| Storage (OS) | 128GB SSD (SATA III, boot drive) |
| Storage (Data) | 1TB 7200RPM Enterprise HDD (SATA III, recording & logs) |
| Storage Expansion | 8x 3.5" hot-swap drive bays, 2x 2.5" internal |
| RAID Support | Hardware RAID 0,1,5,10 (LSI 2208, 1GB cache) |
| Remote Management | IPMI 2.0 with dedicated LAN, KVM-over-IP, virtual media |
| Network | 2 x Gigabit LAN (Intel I350), 1 x dedicated IPMI |
| Video | HDMI, DVI (Matrox G200eW) |
| Audio | 7.1 Channel HD Audio (Realtek ALC888) |
| USB Ports | 4 x USB 3.0, 6 x USB 2.0 |
| PCIe Expansion | 4 x PCIe 3.0 x16, 2 x PCIe 3.0 x8 |
| Power Supply | 2 x 800W Hot-swap Redundant (80+ Platinum) |
| Cooling | 4 x Hot-swap PWM fans (redundant) |
| Special Features | Anti-vibration chassis, wide temperature support (-5°C to 55°C), dust filtration |
| Mounting | Rack mount kit with sliding rails included |
| Dimensions (WxHxD) | 483 x 89 x 720 mm (2U) |
| Weight | Approx. 28 kg (fully loaded) |
| Operating Temperature | -5°C – 55°C (extended range) |
| Storage Temperature | -40°C – 70°C |
| Humidity | 5% – 95% non-condensing |
| Vibration Resistance | 0.5Grms (5-500Hz) operational |
| Certifications | CE, FCC, UL, VCCI, RoHS |
• Supports up to 2,500+ IP endpoints simultaneously • 500+ concurrent intercom sessions • 30,000 hours MTBF • 99.999% availability with redundant configuration • 10-year component longevity commitment
The t-7700h represents the pinnacle of the ITC T-7700 Series hardware line. It is a carrier-grade, dual-processor server specifically engineered for the most demanding IP network audio, intercom, and mass notification systems. Unlike standard IT equipment, the t-7700h is built with industrial-grade components and validated for 24/7/365 continuous operation in harsh environments.
Unmatched Processing Power: Twin Intel Xeon E5-2643V2 processors deliver 12 physical cores (24 threads) with a high 3.5GHz clock speed – ideal for low-latency audio mixing, real-time transcoding, and heavy database loads. 32GB of ECC RAM ensures error-free operation even in high-radiation or electrically noisy environments.
Enterprise Storage Architecture: The hybrid storage configuration separates OS and data: 128GB SSD for rapid boot and software responsiveness, plus a 1TB enterprise HDD for voice recording, event logs, and system backups. Eight hot-swap drive bays allow for massive storage expansion without system downtime.
Designed for Remote Operations: Integrated IPMI 2.0 with dedicated management port provides complete out-of-band control – power cycle, BIOS access, virtual media mounting, and full KVM-over-IP. Manage the server from anywhere in the world without requiring on-site IT staff.
12 cores / 24 threads, 3.5GHz base clock. Handles massive parallel audio processing and thousands of concurrent SIP sessions.
Dedicated management port with HTML5 KVM, virtual media, sensor monitoring, and automated alerting. No additional software required.
Hot-swap PSUs (2+1 optional), hot-swap fans, RAID 1/10, dual NICs, and T-7700SR software failover – zero single points of failure.
Certified for -5°C to 55°C operational temperature. Special cooling design and industrial-grade capacitors.
All capacitors are 105°C rated, Japanese brand. PCB is conformal-coated for humidity and dust resistance. Extended lifecycle components (5+ year availability).
Reinforced drive cages, dampened fan mounts, and shock-absorbing feet. Certified for continuous operation in industrial environments, near heavy machinery.
Special airflow design and industrial-grade fans enable operation from -5°C to 55°C ambient. Ideal for non-air-conditioned comms rooms, outdoor shelters.
t-7700h is guaranteed to be available and supported for a minimum of 7 years from first ship date. Stable BOM, no unexpected component changes.
The t-7700h is designed to grow with your system. Eight hot-swap drive bays support up to 64TB raw storage. Six PCIe 3.0 slots allow for 10/25/40GbE networking, Fibre Channel, hardware DSP cards, or NVMe cache. Two additional processors can be upgraded to higher-core Xeon E5-2600 v2 series.
| Model | Processor | RAM | Storage | Form Factor | Max Endpoints |
|---|---|---|---|---|---|
| T-7700 | Core i5 | 8GB | 128G SSD | 4U Rack/Touch | 500 |
| T-7700A | Core i7 | 16GB | 256G SSD | 4U Rack/Touch | 1,000 |
| t-7700h | Dual Xeon | 32GB+ | 1TB HDD+128G SSD | 2U Rack, no touch | 2,500+ |
t-7700h is a headless server (no integrated display). Designed for dedicated data center or comms room deployment, managed via IPMI or remote desktop.
The t-7700h is the only T-7700 series controller with full hardware redundancy: hot-swap PSUs, hot-swap fans, RAID, and dual CPUs. When combined with T-7700SR software in an active-standby pair, the system achieves 99.999% availability – suitable for emergency response, air traffic control, and defense applications.
Tongfang BMS offers comprehensive deployment packages for t-7700h: on-site installation, SAN/NAS integration, active-standby clustering, and 24/7 enterprise support with 4-hour hardware replacement. Contact sales for SLA details.
