Industrial IP Network Controller with Touch Screen
17.3" LED Capacitive Touch • Intel Core i5 • 8GB RAM • 128G SSD • Dual Gigabit LAN
T-7700 (Hardware)
The central brain of the T-7700 series. T-7700 is a rugged, industrial-grade all-in-one IP network controller featuring a 17.3-inch LED capacitive touch screen. Preloaded with Windows Server 2008 and optimized for ITC T-7700RU/RP software, it serves as the primary hardware platform for broadcasting management, intercom control, and system data exchange.
| Model Number | T-7700 |
| Product Type | Industrial IP Network Controller |
| Display | 17.3" LED-backlit, Capacitive Touch Screen |
| Resolution | 1920 x 1080 (Full HD) |
| Processor | Intel Core i5 (6th Gen or higher) |
| Memory | 8GB DDR4 RAM (expandable) |
| Storage | 128GB SSD (SATA III) |
| Operating System | Windows Server 2008 (pre-installed, optimized) |
| Ethernet | 2 x Gigabit LAN (RJ45) |
| USB Ports | 8 x USB (4x USB 3.0, 4x USB 2.0) |
| Serial Ports | 6 x RS232 (DB9) |
| Video Output | 1 x VGA, 1 x HDMI |
| Audio | Line-out, Mic-in (3.5mm) |
| Expansion | 1 x PCIe x16 slot |
| Power Supply | AC 100-240V, 50/60Hz, 250W |
| Special Feature | Auto power-on after power failure, short-circuit boot trigger |
| Mounting | Rack mount kit included (4U) |
| Dimensions (WxHxD) | 483 x 178 x 450 mm (19" rack) |
| Weight | Approx. 12 kg |
| Operating Temperature | 0°C – 40°C |
| Storage Temperature | -20°C – 60°C |
| Humidity | 10% – 90% non-condensing |
| Certifications | CE, FCC, RoHS |
The T-7700 is the flagship hardware controller for the ITC T-7700 Series IP network audio system. Designed for 24/7 mission-critical operation, it combines a high-performance industrial computer with a large 17.3-inch capacitive touch screen, providing an intuitive local interface for system management, monitoring, and diagnostics.
Preloaded with Windows Server 2008 and rigorously tested with ITC T-7700RU/RP software, the T-7700 offers plug-and-play deployment. Its robust I/O configuration – 6 serial ports, 8 USB, dual Gigabit LAN – ensures seamless integration with peripheral devices such as fire alarm interfaces, external controllers, and backup servers. The auto power-on and short-circuit boot trigger features guarantee automatic recovery after power interruptions, essential for unattended control rooms.
17.3" capacitive touch screen eliminates need for external monitor/keyboard. Full HD resolution for detailed terminal maps and task views.
Designed for continuous operation. Enhanced cooling, anti-vibration chassis, and industrial-grade components.
6x RS232 for legacy fire panels, 8x USB for peripherals, dual LAN for network redundancy or separate management network.
The T-7700 can be ordered with upgraded specifications: Intel Core i7, 16GB/32GB RAM, 256GB/512GB SSD, additional PCIe cards (audio, video capture, fiber optic). Contact ITC sales for BTO/CTO configurations.
| Model | Processor | RAM | Storage | Key Feature |
|---|---|---|---|---|
| T-7700 | Core i5 | 8GB | 128G SSD | 17.3" Touch, 6xCOM, 8xUSB |
| T-7700A | Core i7 | 16GB | 256G SSD | Full HD, dual graphics, recording |
| t-7700h | Dual Xeon | 32GB | 1TB HDD+128G SSD | Enterprise, IPMI, rack |
T-7700 is the standard model; T-7700A and t-7700h offer higher performance for larger deployments.
The T-7700 includes BIOS-level "auto power-on after AC loss" and a hardware short-circuit boot trigger. This ensures the server automatically restarts after power outages and can be remotely power-cycled via dry contact – critical for unmanned sites.
