Agent Releasing Panel

FW2107 - Special Hazard Fire Suppression Control System

UL Listed • Dual Cross-Zone Detection • Abort Function

UL Listed

Agent Releasing Panel

FW2107

UL Listed
Dual-Zone Detection
Quality Tested
Easy Install
Warning: This panel controls fire suppression agent release. Installation and maintenance must be performed by qualified personnel only.

High-performance fire alarm component designed for modern life safety systems. Part of the Maple Armor 2025 series, providing reliability and code compliance for complex building environments.

Product Specifications

Model NumberFW2107
Product NameAgent Releasing Panel
CategoryFire Suppression Control Panel
CertificationUL 864, NFPA 72, NFPA 2001
ManufacturerMaple Armor / Tongfang
Warranty3-Year Comprehensive
Power Supply24VDC (Primary), 120/240VAC (Backup)
Battery Backup24VDC, 12-100 AH (Expandable)
Detection Zones2 Independent Cross-Zones
Release Circuits4 Independent Release Circuits
Abort FunctionManual & Automatic Abort Capability
Time DelaysProgrammable 0-60 Seconds
Supervisory Circuits8 Supervised Inputs
Alarm Outputs6 Form C Relays (5A @ 30VDC)
DisplayBacklit LCD with Status Indicators
CommunicationRS-485, Ethernet Optional
Operating Temperature0°C to +49°C (32°F to 120°F)
Enclosure RatingNEMA 4X (Water & Dust Tight)
Dimensions (HxWxD)20" x 16" x 6" (508 x 406 x 152mm)

Product Overview

The FW2107 (Agent Releasing Panel) provides industry-leading fire detection and notification capabilities. It is fully compatible with Tongfang BMS architecture and optimized for quick field deployment and simplified maintenance.

Cross-Zone Detection

Dual-zone detection system requires activation of both zones before agent release, preventing false discharges.

Manual Abort

Multiple abort options including local panel abort, remote abort stations, and automatic time-based abort.

Programmable Delays

Configurable time delays (0-60 seconds) for personnel evacuation before agent discharge.

Applications
  • Data Centers & Server Rooms
  • Telecommunications Facilities
  • Museums, Archives & Libraries
  • Power Generation & Substations
  • Chemical Storage Areas
  • Flammable Liquid Storage
System Operation Sequence
Standard Operation: Zone 1 Detection → Zone 2 Detection → Alarm Sounds → Time Delay Starts → Personnel Evacuation → Agent Release (if not aborted)

Compatible Suppression Agents

The FW2107 is compatible with various clean agent and gaseous suppression systems:

FM-200®
Clean Agent, Fast Acting
Novec™ 1230
Environmentally Friendly
FE-13™
Low Pressure Agent
CO₂ Systems
High Pressure CO₂
Water Mist
Water-Based Systems
Inergen®
Inert Gas Systems
Agent Selection Guidelines
Considerations
  • Protected hazard type and contents
  • Occupancy and personnel safety
  • Environmental impact concerns
  • Space constraints and pipe routing
Design Support

Tongfang BMS provides engineering support for agent selection, system design, and NFPA compliance.

Contact Engineering

Safety Features & Compliance

Important: Fire suppression systems involve potentially hazardous agents. System design, installation, and maintenance must comply with all applicable codes and standards.
Safety Features
  • Dual-Zone Cross-Zone Detection
  • Manual and Automatic Abort Function
  • Time Delay for Evacuation
  • Supervised Abort Circuits
  • Agent Release Lockout Switches
  • System Fault Monitoring
Compliance Standards
  • NFPA 72 - Fire Alarm & Signaling
  • NFPA 2001 - Clean Agent Systems
  • UL 864 - Control Units
  • ISO 14520 - Gaseous Systems
  • Local AHJ Requirements
Personnel Safety Requirements
Qualified Personnel

Only trained and qualified personnel should install, test, or maintain suppression systems.

Training Requirements

Tongfang BMS offers comprehensive training programs for installers and maintenance personnel.

Documentation

Complete system documentation must be maintained on-site and available to emergency responders.
