FW106 - Fire Alarm Control Panel for Small to Medium Buildings
UL Listed • Compact Design • Easy Installation
FW106
High-performance fire alarm component designed for modern life safety systems. Part of the Maple Armor 2025 series, providing reliability and code compliance for complex building environments.
| Model Number | FW106 |
| Product Name | Compact FACP |
| Category | Fire Alarm Control Panel |
| Certification | UL Listed, ULC Listed |
| Manufacturer | Maple Armor / Tongfang |
| Warranty | Standard 2-Year |
| Power Supply | 120/240VAC, 50/60Hz |
| Battery Backup | 24VDC, 7-18 AH (Included) |
| Max Zones | 6 Conventional Zones |
| Max Devices | Up to 60 Conventional Devices |
| Display | LCD with Backlight |
| Communication | RS-485 for Network/Annuciator |
| Relay Outputs | 4 Programmable Relays |
| Dimensions (HxWxD) | 14" x 12" x 4" (356 x 305 x 102mm) |
| Operating Temperature | 0°C to +49°C (32°F to 120°F) |
| Humidity Range | 10% to 93% RH non-condensing |
The FW106 (Compact FACP) provides industry-leading fire detection and notification capabilities. It is fully compatible with Tongfang BMS architecture and optimized for quick field deployment and simplified maintenance.
Certified for safety and compliance with NFPA 72 standards for fire alarm systems.
Space-saving design ideal for small to medium commercial buildings and multi-family residences.
Plug-and-play installation with pre-wired terminals and clear labeling for fast deployment.
6 Conventional zones with individual LED indicators
Built-in battery charger with supervision
Walk-test and sensitivity test functions
Alarm, trouble, and supervisory indications
Ground fault detection on all circuits
Compatible with conventional smoke/heat detectors
The FW106 Compact FACP is compatible with a wide range of conventional fire safety devices:
